生產能力
Production
capacity
|
3-5模/分鐘（實際產能根據產品工藝要求確定）
3-5molds/min(the
actual speed according to product process requirement)
|
|
工作壓力
5-7molds/min(the
actual speed according to product process requirement)e
|
≤250T (1.無級調節 2.雙對壓）
≤250T(1.Stepless adjustment 2.Bidirectional compress)
|
|
工作行程
Working
stroke
|
上缸≤250mm,下缸≤100mm（1無級調節，2根據產品要求定制）
Up
stroke≤250mm,Down stroke≤100mm(1.Stepless adjustment 2.Bidirectional compress)
|
|
填料高度
Filling
depth
|
≤100mm（1.無級可調，2根據產品實際要求定制）
≤100mm(1.Stepless adjustment 2.Bidirectional compress)
|
|
產品模具
Product mold
|
依產品特點實行一對一定制，（支持一模多出）
Can
be customized according to the tablet features(The mould can compress 1
output more tablets percycle)
|
|
適用形狀
Apply
to shape
|
圓形、方形、異性等，適用于多種形狀
Round,square,or
special-shaped,suitable for a variety of shapes,please consuit
|
|
電機功率
Power
supply
|
18.5kw 22kw(伺服)
|
|
外形尺寸
Weight&size
|
3200mm*1200mm*2100mm （以實際尺寸為準）
(L*W*H)
|
